mei:restore

Indicates restoration of material to an earlier state by cancellation of an editorial or authorial marking or instruction.

Element Information

Model

Children: mei:abbr, mei:accid, mei:address, mei:annot, mei:arpeg, mei:artic, mei:bTrem, mei:barLine, mei:beam, mei:beamSpan, mei:beatRpt, mei:bend, mei:bibl, mei:bloc, mei:breath, mei:chord, mei:clef, mei:clefGrp, mei:corpName, mei:country, mei:cpMark, mei:custos, mei:date, mei:dir, mei:district, mei:dot, mei:dynam, mei:expan, mei:fTrem, mei:fermata, mei:fig, mei:fing, mei:fingGrp, mei:geogFeat, mei:geogName, mei:gliss, mei:hairpin, mei:halfmRpt, mei:harm, mei:harpPedal, mei:identifier, mei:ineume, mei:keySig, mei:lb, mei:ligature, mei:lyrics, mei:mRest, mei:mRpt, mei:mRpt2, mei:mSpace, mei:measure, mei:mei_model.editLike, mei:mei_model.fLike, mei:mei_model.graphicprimitiveLike, mei:mei_model.layerLike, mei:mei_model.sectionLike, mei:mei_model.transcriptionLike, mei:mensur, mei:meterSig, mei:meterSigGrp, mei:midi, mei:mordent, mei:multiRest, mei:multiRpt, mei:name, mei:note, mei:num, mei:octave, mei:ornam, mei:pad, mei:pb, mei:pedal, mei:periodName, mei:persName, mei:phrase, mei:postBox, mei:postCode, mei:proport, mei:ptr, mei:ref, mei:region, mei:reh, mei:rend, mei:repository, mei:rest, mei:settlement, mei:slur, mei:space, mei:stack, mei:staff, mei:street, mei:styleName, mei:symbol, mei:tempo, mei:tie, mei:title, mei:trill, mei:tuplet, mei:tupletSpan, mei:turn, mei:uneume

Attributes

QName

Type

Fixed

Default

Use

Inheritable

Annotation

cert

mei:mei_data.CERTAINTY

optional

Signifies the degree of certainty or precision associated with a
feature.

desc

xs:string

optional

Provides a description of the means of restoration, 'stet' or
'strike-down', for example.

evidence

xs:NMTOKEN

optional

Indicates the nature of the evidence supporting the reliability or
accuracy of the intervention or interpretation. Suggested values include: 'internal',
'external', 'conjecture'.

facs

restriction of list of mei:mei_data.URI

optional

Permits the current element to reference a facsimile surface or image zone
which corresponds to it.

hand

mei:mei_data.URI

optional

Signifies the hand responsible for an action. The value must be the ID of
a <hand> element declared in the header.

label

xs:string

optional

Provides a name or label for an element. The value may be any
string.

optional

Provides a number-like designation for an element.

resp

restriction of list of mei:mei_data.URI

optional

Indicates the agent(s) responsible for some aspect of the text's creation,
transcription, editing, or encoding. Its value must point to one or more identifiers
declared in the document header.

seq

xs:positiveInteger

optional

Used to assign a sequence number related to the order in which the encoded
features carrying this attribute are believed to have occurred.

source

restriction of list of mei:mei_data.URI

optional

Contains a list of one or more pointers indicating the sources which
attest to a given reading. Each value should correspond to the ID of a <source>
element located in the document header.

subtype

xs:NMTOKEN

optional

Provide any sub-classification for the element, additional to that given
by its type attribute.

translit

xs:NMTOKEN

optional

Specifies the transliteration technique used.

type

xs:NMTOKEN

optional

Characterizes the element in some sense, using any convenient
classification scheme or typology.

xml:base

mei:mei_data.URI

optional

Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.

xml:id

xs:ID

optional

Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.

xml:lang

xs:language

optional

Identifies the language of the element's content. The values for this
attribute are language 'tags' as defined in BCP 47. All language tags that make use of
private use sub-tags must be documented in a corresponding language element in the MEI
header whose id attribute is the same as the language tag's value.

Source

<xs:element name="restore" substitutionGroup="mei:mei_model.transcriptionLike">
  <xs:annotation>
    <xs:documentation>Indicates restoration of material to an earlier state by cancellation of an editorial or authorial marking or instruction.</xs:documentation>
  </xs:annotation>
  <xs:complexType mixed="true">
    <xs:choice minOccurs="0" maxOccurs="unbounded">
      <xs:group ref="mei:mei_model.textphraseLike"/>
      <xs:group ref="mei:mei_model.eventLike"/>
      <xs:group ref="mei:mei_model.eventLike.neumes"/>
      <xs:group ref="mei:mei_model.controleventLike"/>
      <xs:group ref="mei:mei_model.lyricsLike"/>
      <xs:group ref="mei:mei_model.midiLike"/>
      <xs:element ref="mei:mei_model.editLike"/>
      <xs:element ref="mei:mei_model.transcriptionLike"/>
      <xs:group ref="mei:mei_model.eventLike.measureFilling"/>
      <xs:group ref="mei:mei_model.noteModifierLike"/>
      <xs:element ref="mei:mei_model.sectionLike"/>
      <xs:group ref="mei:mei_model.measureLike"/>
      <xs:group ref="mei:mei_model.staffLike"/>
      <xs:element ref="mei:mei_model.layerLike"/>
      <xs:element ref="mei:mei_model.graphicprimitiveLike"/>
      <xs:element ref="mei:mei_model.fLike"/>
    </xs:choice>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.edit.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.lang.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.trans.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.typed.attributes"/>
    <xs:attribute name="desc" type="xs:string">
      <xs:annotation>
        <xs:documentation>Provides a description of the means of restoration, 'stet' or 'strike-down', for example.</xs:documentation>
      </xs:annotation>
    </xs:attribute>
  </xs:complexType>
</xs:element>
