mei:mei_model.sectionLike

Element Information

Model

mei:expansion* , (mei:mei_model.appLike | mei:mei_model.divLike | (mei:pb) | mei:sb | (mei:annot) | mei:mei_model.graphicprimitiveLike | mei:mei_model.editLike | mei:mei_model.transcriptionLike | mei:mei_model.endingLike | (mei:scoreDef) | mei:mei_model.sectionLike | (mei:staff) | (mei:staffDef) | (mei:measure))
Children: mei:annot, mei:expansion, mei:measure, mei:mei_model.appLike, mei:mei_model.divLike, mei:mei_model.editLike, mei:mei_model.endingLike, mei:mei_model.graphicprimitiveLike, mei:mei_model.sectionLike, mei:mei_model.transcriptionLike, mei:pb, mei:sb, mei:scoreDef, mei:staff, mei:staffDef

Attributes

QName Type Fixed Default Use Inheritable Annotation
copyof mei:mei_data.URI optional
Points to an element of which the current element is a
copy.
corresp restriction of list of mei:mei_data.URI optional
Used to point to other elements that correspond to this one in a generic
fashion.
decls restriction of list of mei:mei_data.URI optional
Identifies one or more metadata elements within the header, which are
understood to apply to the element bearing this attribute and its
content.
evaluate restriction of xs:token optional
Specifies the intended meaning when a participant in a relationship is
itself a pointer.
facs restriction of list of mei:mei_data.URI optional
Permits the current element to reference a facsimile surface or image zone
which corresponds to it.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
n optional
Provides a number-like designation for an element.
next restriction of list of mei:mei_data.URI optional
Used to point to the next event(s) in a user-defined
collection.
prev restriction of list of mei:mei_data.URI optional
Points to the previous event(s) in a user-defined
collection.
restart mei:mei_data.BOOLEAN optional
Indicates that staves begin again with this section.
sameas restriction of list of mei:mei_data.URI optional
Points to an element that is the same as the current element but is not a
literal copy of the current element.
subtype xs:NMTOKEN optional
Provide any sub-classification for the element, additional to that given
by its type attribute.
synch restriction of list of mei:mei_data.URI optional
Points to elements that are synchronous with the current
element.
target restriction of list of mei:mei_data.URI optional
Allows the use of one or more previously-undeclared URIs to identify
passive participants in a relationship; that is, the entities pointed
"to".
targettype xs:NMTOKEN optional
Characterization of target resource(s) using any convenient classification
scheme or typology.
type xs:NMTOKEN optional
Characterizes the element in some sense, using any convenient
classification scheme or typology.
when mei:mei_data.URI optional
Indicates the point of occurrence of this feature along a time line. Its
value must be the ID of a when element elsewhere in the document.
xlink:actuate restriction of xs:token optional
Defines whether a link occurs automatically or must be requested by the
user.
xlink:role mei:mei_data.URI optional
Characterization of the relationship between resources. The value of the
role attribute must be a URI.
xlink:show restriction of xs:token optional
Defines how a remote resource is rendered.
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.

Used By

Element Groups mei:mei_model.scorePart, mei:mei_model.sectionPart
Elements mei:abbr, mei:add, mei:corr, mei:damage, mei:del, mei:expan, mei:orig, mei:reg, mei:restore, mei:sic, mei:supplied, mei:unclear

Source

<xs:element name="mei_model.sectionLike" abstract="true">
  <xs:complexType>
    <xs:sequence>
      <xs:element minOccurs="0" maxOccurs="unbounded" ref="mei:expansion"/>
      <xs:choice minOccurs="0" maxOccurs="unbounded">
        <xs:element ref="mei:mei_model.appLike"/>
        <xs:element ref="mei:mei_model.divLike"/>
        <xs:group ref="mei:mei_model.milestoneLike.music"/>
        <xs:group ref="mei:mei_model.annotLike"/>
        <xs:element ref="mei:mei_model.graphicprimitiveLike"/>
        <xs:element ref="mei:mei_model.editLike"/>
        <xs:element ref="mei:mei_model.transcriptionLike"/>
        <xs:group ref="mei:mei_model.sectionPart"/>
      </xs:choice>
    </xs:sequence>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.declaring.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.pointing.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.section.vis.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.section.anl.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.targeteval.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.typed.attributes"/>
  </xs:complexType>
</xs:element>

Sample
