mei:annot

(annotation) – Provides a short statement explaining the text or indicating
the basis for an assertion.

Element Information

Model

Attributes

QName Type Fixed Default Use Inheritable Annotation
analog xs:string optional
Contains a reference to a field or element in another descriptive encoding
system to which this MEI element is comparable.
copyof mei:mei_data.URI optional
Points to an element of which the current element is a
copy.
corresp restriction of list of mei:mei_data.URI optional
Used to point to other elements that correspond to this one in a generic
fashion.
dots mei:mei_data.AUGMENTDOT optional
Records the number of augmentation dots required by a dotted
duration.
dur restriction of list of mei:mei_data.DURATION.additive optional
Records duration using optionally dotted, relative durational values
provided by the data.DURATION datatype. When the duration is "irrational", as is sometimes
the case with tuplets, multiple space-separated values that add up to the total duration
may be used. When dotted values are present, the dots attribute must be
ignored.
dur.ges mei:mei_data.DURATION.gestural optional
Records performed duration information that differs from the written
duration. Its value may be expressed in several forms; that is, ppq (MIDI clicks and
MusicXML 'divisions'), Humdrum **recip values, beats, seconds, or mensural duration
values.
endid mei:mei_data.URI optional
Indicates the final element in a sequence of events to which the feature
applies.
evaluate restriction of xs:token optional
Specifies the intended meaning when a participant in a relationship is
itself a pointer.
facs restriction of list of mei:mei_data.URI optional
Permits the current element to reference a facsimile surface or image zone
which corresponds to it.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
layer restriction of list of xs:positiveInteger optional
Identifies the layer to which a feature applies.
n optional
Provides a number-like designation for an element.
next restriction of list of mei:mei_data.URI optional
Used to point to the next event(s) in a user-defined
collection.
plist restriction of list of mei:mei_data.URI optional
Contains a space separated list of references that identify active
participants in a collection/relationship, such as notes under a phrase mark; that is, the
entities pointed "from".
prev restriction of list of mei:mei_data.URI optional
Points to the previous event(s) in a user-defined
collection.
resp restriction of list of mei:mei_data.URI optional
Indicates the agent(s) responsible for some aspect of the text's creation,
transcription, editing, or encoding. Its value must point to one or more identifiers
declared in the document header.
sameas restriction of list of mei:mei_data.URI optional
Points to an element that is the same as the current element but is not a
literal copy of the current element.
source restriction of list of mei:mei_data.URI optional
Contains a list of one or more pointers indicating the sources which
attest to a given reading. Each value should correspond to the ID of a <source>
element located in the document header.
staff restriction of list of xs:positiveInteger optional
Signifies the staff on which a notated event occurs or to which a control
event applies. Mandatory when applicable.
startid mei:mei_data.URI optional
Holds a reference to the first element in a sequence of events to which
the feature applies.
subtype xs:NMTOKEN optional
Provide any sub-classification for the element, additional to that given
by its type attribute.
synch restriction of list of mei:mei_data.URI optional
Points to elements that are synchronous with the current
element.
translit xs:NMTOKEN optional
Specifies the transliteration technique used.
tstamp mei:mei_data.BEAT optional
Encodes the onset time in terms of musical time, i.e.,
beats[.fractional_beat_part].
tstamp.ges mei:mei_data.DURATION.gestural optional
Captures performed onset time in several forms; that is, ppq (MIDI clicks
and MusicXML 'divisions'), Humdrum **recip values, beats, seconds, or mensural duration
values.
tstamp.real mei:mei_data.ISOTIME optional
Used to record the onset time in terms of ISO time.
tstamp2 mei:mei_data.MEASUREBEAT optional
Encodes the ending point of an event in terms of musical time, i.e., a
count of measures plus a beat location.
type xs:NMTOKEN optional
Characterizes the element in some sense, using any convenient
classification scheme or typology.
when mei:mei_data.URI optional
Indicates the point of occurrence of this feature along a time line. Its
value must be the ID of a when element elsewhere in the document.
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.
xml:lang xs:language optional
Identifies the language of the element's content. The values for this
attribute are language 'tags' as defined in BCP 47. All language tags that make use of
private use sub-tags must be documented in a corresponding language element in the MEI
header whose id attribute is the same as the language tag's value.

Used By

Source

<xs:element name="annot">
  <xs:annotation>
    <xs:documentation>(annotation) – Provides a short statement explaining the text or indicating the basis for an assertion.</xs:documentation>
  </xs:annotation>
  <xs:complexType mixed="true">
    <xs:choice minOccurs="0" maxOccurs="unbounded">
      <xs:element ref="mei:mei_model.headLike"/>
      <xs:element ref="mei:mei_model.textcomponentLike"/>
      <xs:group ref="mei:mei_model.textphraseLike"/>
      <xs:element ref="mei:mei_model.editLike"/>
      <xs:element ref="mei:mei_model.transcriptionLike"/>
    </xs:choice>
    <xs:attributeGroup ref="mei:mei_att.bibl.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.lang.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.source.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.annot.log.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.annot.ges.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.annot.anl.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.plist.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.responsibility.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.targeteval.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.typed.attributes"/>
  </xs:complexType>
</xs:element>

Sample
