analog |
xs:string |
|
|
optional |
|
Contains a reference to a field or element in another descriptive encoding
system to which this MEI element is comparable. |
|
copyof |
mei:mei_data.URI |
|
|
optional |
|
Points to an element of which the current element is a
copy. |
|
corresp |
restriction of list of mei:mei_data.URI |
|
|
optional |
|
Used to point to other elements that correspond to this one in a generic
fashion. |
|
endho |
mei:mei_data.MEASUREMENTREL |
|
|
optional |
|
Records the horizontal adjustment of a feature's
programmatically-determined end point. |
|
endto |
mei:mei_data.TSTAMPOFFSET |
|
|
optional |
|
Records a timestamp adjustment of a feature's programmatically-determined
end point. |
|
evaluate |
restriction of xs:token |
|
|
optional |
|
Specifies the intended meaning when a participant in a relationship is
itself a pointer. |
|
facs |
restriction of list of mei:mei_data.URI |
|
|
optional |
|
Permits the current element to reference a facsimile surface or image zone
which corresponds to it. |
|
func |
restriction of xs:token |
|
|
optional |
|
Records the function of a tempo indication. |
|
ho |
mei:mei_data.MEASUREMENTREL |
|
|
optional |
|
Records a horizontal adjustment to a feature's programmatically-determined
location in terms of staff interline distance; that is, in units of 1/2 the distance
between adjacent staff lines. |
|
label |
xs:string |
|
|
optional |
|
Provides a name or label for an element. The value may be any
string. |
|
layer |
restriction of list of xs:positiveInteger |
|
|
optional |
|
Identifies the layer to which a feature applies. |
|
midi.bpm |
mei:mei_data.MIDIBPM |
|
|
optional |
|
Captures the number of *quarter notes* per minute. In MIDI, a beat is
always defined as a quarter note, *not the numerator of the time signature or the
metronomic indication*. |
|
midi.mspb |
mei:mei_data.MIDIMSPB |
|
|
optional |
|
Records the number of microseconds per *quarter note*. In MIDI, a beat is
always defined as a quarter note, *not the numerator of the time signature or the
metronomic indication*. At 120 quarter notes per minute, each quarter note will last
500,000 microseconds. |
|
mm |
mei:mei_data.TEMPOVALUE |
|
|
optional |
|
Used to describe tempo in terms of beats (often the meter signature
denominator) per minute, ala M.M. (Maezel's Metronome). Do not confuse this attribute with
midi.bpm or midi.mspb. In MIDI, a beat is always defined as a quarter note, *not the
numerator of the time signature or the metronomic indication*. |
|
mm.dots |
mei:mei_data.AUGMENTDOT |
|
|
optional |
|
Records the number of augmentation dots required by a dotted metronome
unit. |
|
mm.unit |
mei:mei_data.DURATION |
|
|
optional |
|
Captures the metronomic unit. |
|
n |
|
|
|
optional |
|
Provides a number-like designation for an element. |
|
next |
restriction of list of mei:mei_data.URI |
|
|
optional |
|
Used to point to the next event(s) in a user-defined
collection. |
|
place |
mei:mei_data.STAFFREL |
|
|
optional |
|
Captures the placement of the item with respect to the staff with which it
is associated. |
|
plist |
restriction of list of mei:mei_data.URI |
|
|
optional |
|
Contains a space separated list of references that identify active
participants in a collection/relationship, such as notes under a phrase mark; that is, the
entities pointed "from". |
|
prev |
restriction of list of mei:mei_data.URI |
|
|
optional |
|
Points to the previous event(s) in a user-defined
collection. |
|
sameas |
restriction of list of mei:mei_data.URI |
|
|
optional |
|
Points to an element that is the same as the current element but is not a
literal copy of the current element. |
|
staff |
restriction of list of xs:positiveInteger |
|
|
optional |
|
Signifies the staff on which a notated event occurs or to which a control
event applies. Mandatory when applicable. |
|
startho |
mei:mei_data.MEASUREMENTREL |
|
|
optional |
|
Records the horizontal adjustment of a feature's
programmatically-determined start point. |
|
startid |
mei:mei_data.URI |
|
|
optional |
|
Holds a reference to the first element in a sequence of events to which
the feature applies. |
|
startto |
mei:mei_data.TSTAMPOFFSET |
|
|
optional |
|
Records a timestamp adjustment of a feature's programmatically-determined
start point. |
|
subtype |
xs:NMTOKEN |
|
|
optional |
|
Provide any sub-classification for the element, additional to that given
by its type attribute. |
|
synch |
restriction of list of mei:mei_data.URI |
|
|
optional |
|
Points to elements that are synchronous with the current
element. |
|
to |
mei:mei_data.TSTAMPOFFSET |
|
|
optional |
|
Records a timestamp adjustment of a feature's programmatically-determined
location in terms of musical time; that is, beats. |
|
translit |
xs:NMTOKEN |
|
|
optional |
|
Specifies the transliteration technique used. |
|
tstamp |
mei:mei_data.BEAT |
|
|
optional |
|
Encodes the onset time in terms of musical time, i.e.,
beats[.fractional_beat_part]. |
|
tstamp.ges |
mei:mei_data.DURATION.gestural |
|
|
optional |
|
Captures performed onset time in several forms; that is, ppq (MIDI clicks
and MusicXML 'divisions'), Humdrum **recip values, beats, seconds, or mensural duration
values. |
|
tstamp.real |
mei:mei_data.ISOTIME |
|
|
optional |
|
Used to record the onset time in terms of ISO time. |
|
type |
xs:NMTOKEN |
|
|
optional |
|
Characterizes the element in some sense, using any convenient
classification scheme or typology. |
|
vo |
mei:mei_data.MEASUREMENTREL |
|
|
optional |
|
Records the vertical adjustment of a feature's programmatically-determined
location in terms of staff interline distance; that is, in units of 1/2 the distance
between adjacent staff lines. |
|
when |
mei:mei_data.URI |
|
|
optional |
|
Indicates the point of occurrence of this feature along a time line. Its
value must be the ID of a when element elsewhere in the document. |
|
x |
xs:decimal |
|
|
optional |
|
Encodes an x coordinate for a feature in an output coordinate system. When
it is necessary to record the placement of a feature in a facsimile image, use the facs
attribute. |
|
xml:base |
mei:mei_data.URI |
|
|
optional |
|
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references. |
|
xml:id |
xs:ID |
|
|
optional |
|
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value. |
|
xml:lang |
xs:language |
|
|
optional |
|
Identifies the language of the element's content. The values for this
attribute are language 'tags' as defined in BCP 47. All language tags that make use of
private use sub-tags must be documented in a corresponding language element in the MEI
header whose id attribute is the same as the language tag's value. |
|
y |
xs:decimal |
|
|
optional |
|
Encodes an y coordinate for a feature in an output coordinate system. When
it is necessary to record the placement of a feature in a facsimile image, use the facs
attribute. |
|
