mei:halfmRpt

(half-measure repeat) – A half-measure repeat in any
meter.

Element Information

Model

Attributes

QName Type Fixed Default Use Inheritable Annotation
altsym mei:mei_data.URI optional
Provides a way of pointing to a user-defined symbol. It must contain an ID
of a <symbolDef> element elsewhere in the document.
color mei:mei_data.COLOR optional
Used to indicate visual appearance. Do not confuse this with the musical
term 'color' as used in pre-CMN notation.
copyof mei:mei_data.URI optional
Points to an element of which the current element is a
copy.
corresp restriction of list of mei:mei_data.URI optional
Used to point to other elements that correspond to this one in a generic
fashion.
dur mei:mei_data.DURATION optional
Records the duration of a feature using the relative durational values
provided by the data.DURATION datatype.
expand mei:mei_data.BOOLEAN optional
Indicates whether to render a repeat symbol or the source material to
which it refers. A value of 'true' renders the source material, while 'false' displays the
repeat symbol.
facs restriction of list of mei:mei_data.URI optional
Permits the current element to reference a facsimile surface or image zone
which corresponds to it.
fontfam mei:mei_data.FONTFAMILY optional
Contains the name of a font-family.
fontname mei:mei_data.FONTNAME optional
Holds the name of a font.
fontsize mei:mei_data.FONTSIZE optional
Indicates the size of a font expressed in printers' points, i.e., 1/72nd
of an inch, relative terms, e.g., "small", "larger", etc., or percentage values relative
to "normal" size, e.g., "125%".
fontstyle mei:mei_data.FONTSTYLE optional
Records the style of a font, i.e, italic, oblique, or
normal.
fontweight mei:mei_data.FONTWEIGHT optional
Used to indicate bold type.
glyphname xs:string optional
Glyph name.
glyphnum restriction of xs:string optional
Numeric glyph reference in hexadecimal notation, e.g. "#xE000" or
"U+E000". N.B. SMuFL version 1.18 uses the range U+E000 - U+ECBF.
ho mei:mei_data.MEASUREMENTREL optional
Records a horizontal adjustment to a feature's programmatically-determined
location in terms of staff interline distance; that is, in units of 1/2 the distance
between adjacent staff lines.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
layer restriction of list of xs:positiveInteger optional
Identifies the layer to which a feature applies.
n optional
Provides a number-like designation for an element.
next restriction of list of mei:mei_data.URI optional
Used to point to the next event(s) in a user-defined
collection.
prev restriction of list of mei:mei_data.URI optional
Points to the previous event(s) in a user-defined
collection.
sameas restriction of list of mei:mei_data.URI optional
Points to an element that is the same as the current element but is not a
literal copy of the current element.
staff restriction of list of xs:positiveInteger optional
Signifies the staff on which a notated event occurs or to which a control
event applies. Mandatory when applicable.
synch restriction of list of mei:mei_data.URI optional
Points to elements that are synchronous with the current
element.
to mei:mei_data.TSTAMPOFFSET optional
Records a timestamp adjustment of a feature's programmatically-determined
location in terms of musical time; that is, beats.
tstamp mei:mei_data.BEAT optional
Encodes the onset time in terms of musical time, i.e.,
beats[.fractional_beat_part].
tstamp.ges mei:mei_data.DURATION.gestural optional
Captures performed onset time in several forms; that is, ppq (MIDI clicks
and MusicXML 'divisions'), Humdrum **recip values, beats, seconds, or mensural duration
values.
tstamp.real mei:mei_data.ISOTIME optional
Used to record the onset time in terms of ISO time.
vo mei:mei_data.MEASUREMENTREL optional
Records the vertical adjustment of a feature's programmatically-determined
location in terms of staff interline distance; that is, in units of 1/2 the distance
between adjacent staff lines.
when mei:mei_data.URI optional
Indicates the point of occurrence of this feature along a time line. Its
value must be the ID of a when element elsewhere in the document.
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.

Used By

Element Groups mei:mei_model.eventLike.cmn, mei:mei_model.eventLike.cmn_alternation, mei:mei_model.eventLike.cmn_sequence, mei:mei_model.eventLike.cmn_sequenceOptional, mei:mei_model.eventLike.cmn_sequenceOptionalRepeatable, mei:mei_model.eventLike.cmn_sequenceRepeatable

Source

<xs:element name="halfmRpt">
  <xs:annotation>
    <xs:documentation>(half-measure repeat) – A half-measure repeat in any meter.</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.halfmRpt.log.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.halfmRpt.vis.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.halfmRpt.anl.attributes"/>
  </xs:complexType>
</xs:element>

Sample
