mei:mSpace

(measure space) – A measure containing only empty space in any
meter.

Element Information

Model

Attributes

QName Type Fixed Default Use Inheritable Annotation
altsym mei:mei_data.URI optional
Provides a way of pointing to a user-defined symbol. It must contain an ID
of a <symbolDef> element elsewhere in the document.
copyof mei:mei_data.URI optional
Points to an element of which the current element is a
copy.
corresp restriction of list of mei:mei_data.URI optional
Used to point to other elements that correspond to this one in a generic
fashion.
cutout restriction of xs:token optional
"Cut-out" style indicated for this measure.
dots mei:mei_data.AUGMENTDOT optional
Records the number of augmentation dots required by a dotted
duration.
dur mei:mei_data.DURATION optional
Records the duration of a feature using the relative durational values
provided by the data.DURATION datatype.
dur.ges mei:mei_data.DURATION.gestural optional
Records performed duration information that differs from the written
duration. Its value may be expressed in several forms; that is, ppq (MIDI clicks and
MusicXML 'divisions'), Humdrum **recip values, beats, seconds, or mensural duration
values.
facs restriction of list of mei:mei_data.URI optional
Permits the current element to reference a facsimile surface or image zone
which corresponds to it.
fermata mei:mei_data.PLACE optional
Indicates the attachment of a fermata to this element. If visual
information about the fermata needs to be recorded, then a <fermata> element should
be employed instead.
instr mei:mei_data.URI optional
Provides a way of pointing to a MIDI instrument definition. It must
contain the ID of an <instrDef> element elsewhere in the
document.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
layer restriction of list of xs:positiveInteger optional
Identifies the layer to which a feature applies.
n optional
Provides a number-like designation for an element.
next restriction of list of mei:mei_data.URI optional
Used to point to the next event(s) in a user-defined
collection.
prev restriction of list of mei:mei_data.URI optional
Points to the previous event(s) in a user-defined
collection.
sameas restriction of list of mei:mei_data.URI optional
Points to an element that is the same as the current element but is not a
literal copy of the current element.
staff restriction of list of xs:positiveInteger optional
Signifies the staff on which a notated event occurs or to which a control
event applies. Mandatory when applicable.
synch restriction of list of mei:mei_data.URI optional
Points to elements that are synchronous with the current
element.
tstamp mei:mei_data.BEAT optional
Encodes the onset time in terms of musical time, i.e.,
beats[.fractional_beat_part].
tstamp.ges mei:mei_data.DURATION.gestural optional
Captures performed onset time in several forms; that is, ppq (MIDI clicks
and MusicXML 'divisions'), Humdrum **recip values, beats, seconds, or mensural duration
values.
tstamp.real mei:mei_data.ISOTIME optional
Used to record the onset time in terms of ISO time.
visible mei:mei_data.BOOLEAN optional
Indicates if a feature should be rendered when the notation is presented
graphically or sounded when it is presented in an aural form.
when mei:mei_data.URI optional
Indicates the point of occurrence of this feature along a time line. Its
value must be the ID of a when element elsewhere in the document.
x xs:decimal optional
Encodes an x coordinate for a feature in an output coordinate system. When
it is necessary to record the placement of a feature in a facsimile image, use the facs
attribute.
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.
y xs:decimal optional
Encodes an y coordinate for a feature in an output coordinate system. When
it is necessary to record the placement of a feature in a facsimile image, use the facs
attribute.

Used By

Element Groups mei:mei_model.eventLike.measureFilling, mei:mei_model.eventLike.measureFilling_alternation, mei:mei_model.eventLike.measureFilling_sequence, mei:mei_model.eventLike.measureFilling_sequenceOptional, mei:mei_model.eventLike.measureFilling_sequenceOptionalRepeatable, mei:mei_model.eventLike.measureFilling_sequenceRepeatable

Source

<xs:element name="mSpace">
  <xs:annotation>
    <xs:documentation>(measure space) – A measure containing only empty space in any meter.</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.mSpace.log.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.mSpace.vis.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.mSpace.ges.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.mSpace.anl.attributes"/>
  </xs:complexType>
</xs:element>

Sample
