mei:rdg

(reading) – Contains a single reading within a textual
variation.

Element Information

Model

Attributes

QName Type Fixed Default Use Inheritable Annotation
cause xs:NMTOKEN optional
Classifies the cause for the variant reading, according to any appropriate
typology of possible origins.
copyof mei:mei_data.URI optional
Points to an element of which the current element is a
copy.
corresp restriction of list of mei:mei_data.URI optional
Used to point to other elements that correspond to this one in a generic
fashion.
evaluate restriction of xs:token optional
Specifies the intended meaning when a participant in a relationship is
itself a pointer.
hand mei:mei_data.URI optional
Signifies the hand responsible for an action. The value must be the ID of
a <hand> element declared in the header.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
n optional
Provides a number-like designation for an element.
next restriction of list of mei:mei_data.URI optional
Used to point to the next event(s) in a user-defined
collection.
prev restriction of list of mei:mei_data.URI optional
Points to the previous event(s) in a user-defined
collection.
resp restriction of list of mei:mei_data.URI optional
Indicates the agent(s) responsible for some aspect of the text's creation,
transcription, editing, or encoding. Its value must point to one or more identifiers
declared in the document header.
sameas restriction of list of mei:mei_data.URI optional
Points to an element that is the same as the current element but is not a
literal copy of the current element.
seq xs:positiveInteger optional
Used to assign a sequence number related to the order in which the encoded
features carrying this attribute are believed to have occurred.
source restriction of list of mei:mei_data.URI optional
Contains a list of one or more pointers indicating the sources which
attest to a given reading. Each value should correspond to the ID of a <source>
element located in the document header.
subtype xs:NMTOKEN optional
Provide any sub-classification for the element, additional to that given
by its type attribute.
synch restriction of list of mei:mei_data.URI optional
Points to elements that are synchronous with the current
element.
target restriction of list of mei:mei_data.URI optional
Allows the use of one or more previously-undeclared URIs to identify
passive participants in a relationship; that is, the entities pointed
"to".
targettype xs:NMTOKEN optional
Characterization of target resource(s) using any convenient classification
scheme or typology.
type xs:NMTOKEN optional
Characterizes the element in some sense, using any convenient
classification scheme or typology.
when mei:mei_data.URI optional
Indicates the point of occurrence of this feature along a time line. Its
value must be the ID of a when element elsewhere in the document.
xlink:actuate restriction of xs:token optional
Defines whether a link occurs automatically or must be requested by the
user.
xlink:role mei:mei_data.URI optional
Characterization of the relationship between resources. The value of the
role attribute must be a URI.
xlink:show restriction of xs:token optional
Defines how a remote resource is rendered.
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.

Used By

Source

<xs:element name="rdg">
  <xs:annotation>
    <xs:documentation>(reading) – Contains a single reading within a textual variation.</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element minOccurs="0" maxOccurs="unbounded" ref="mei:expansion"/>
      <xs:choice minOccurs="0" maxOccurs="unbounded">
        <xs:element ref="mei:mei_model.appLike"/>
        <xs:element ref="mei:mei_model.divLike"/>
        <xs:group ref="mei:mei_model.milestoneLike.music"/>
        <xs:element ref="mei:mei_model.staffGrpLike"/>
        <xs:group ref="mei:mei_model.annotLike"/>
        <xs:element ref="mei:mei_model.graphicprimitiveLike"/>
        <xs:element ref="mei:mei_model.editLike"/>
        <xs:element ref="mei:mei_model.transcriptionLike"/>
        <xs:group ref="mei:mei_model.rdgPart.critapp"/>
        <xs:group ref="mei:mei_model.sectionPart"/>
      </xs:choice>
    </xs:sequence>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.crit.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.pointing.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.rdg.anl.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.targeteval.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.typed.attributes"/>
  </xs:complexType>
</xs:element>

Sample
