mei:mei_model.sylLike

Element Information

Model

(mei:address) | (mei:annot) | (mei:bibl) | (mei:date) | mei:abbr | mei:expan | (mei:identifier) | (mei:lb) | (mei:num) | mei:name | mei:corpName | mei:persName | (mei:repository) | (mei:geogName) | mei:rend | mei:stack | (mei:title) | (mei:fig) | mei:bloc | mei:country | mei:district | mei:geogFeat | mei:region | mei:settlement | mei:postBox | mei:postCode | mei:street | mei:periodName | mei:styleName | mei:ptr | mei:ref | mei:symbol | mei:mei_model.editLike | mei:mei_model.transcriptionLike
Children: mei:abbr, mei:address, mei:annot, mei:bibl, mei:bloc, mei:corpName, mei:country, mei:date, mei:district, mei:expan, mei:fig, mei:geogFeat, mei:geogName, mei:identifier, mei:lb, mei:mei_model.editLike, mei:mei_model.transcriptionLike, mei:name, mei:num, mei:periodName, mei:persName, mei:postBox, mei:postCode, mei:ptr, mei:ref, mei:region, mei:rend, mei:repository, mei:settlement, mei:stack, mei:street, mei:styleName, mei:symbol, mei:title

Attributes

QName Type Fixed Default Use Inheritable Annotation
con restriction of xs:token optional
Describes the symbols typically used to indicate breaks between syllables
and their functions.
copyof mei:mei_data.URI optional
Points to an element of which the current element is a
copy.
corresp restriction of list of mei:mei_data.URI optional
Used to point to other elements that correspond to this one in a generic
fashion.
facs restriction of list of mei:mei_data.URI optional
Permits the current element to reference a facsimile surface or image zone
which corresponds to it.
fontfam mei:mei_data.FONTFAMILY optional
Contains the name of a font-family.
fontname mei:mei_data.FONTNAME optional
Holds the name of a font.
fontsize mei:mei_data.FONTSIZE optional
Indicates the size of a font expressed in printers' points, i.e., 1/72nd
of an inch, relative terms, e.g., "small", "larger", etc., or percentage values relative
to "normal" size, e.g., "125%".
fontstyle mei:mei_data.FONTSTYLE optional
Records the style of a font, i.e, italic, oblique, or
normal.
fontweight mei:mei_data.FONTWEIGHT optional
Used to indicate bold type.
halign mei:mei_data.HORIZONTALALIGNMENT optional
Records horizontal alignment.
ho mei:mei_data.MEASUREMENTREL optional
Records a horizontal adjustment to a feature's programmatically-determined
location in terms of staff interline distance; that is, in units of 1/2 the distance
between adjacent staff lines.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
n optional
Provides a number-like designation for an element.
next restriction of list of mei:mei_data.URI optional
Used to point to the next event(s) in a user-defined
collection.
prev restriction of list of mei:mei_data.URI optional
Points to the previous event(s) in a user-defined
collection.
sameas restriction of list of mei:mei_data.URI optional
Points to an element that is the same as the current element but is not a
literal copy of the current element.
synch restriction of list of mei:mei_data.URI optional
Points to elements that are synchronous with the current
element.
to mei:mei_data.TSTAMPOFFSET optional
Records a timestamp adjustment of a feature's programmatically-determined
location in terms of musical time; that is, beats.
translit xs:NMTOKEN optional
Specifies the transliteration technique used.
vo mei:mei_data.MEASUREMENTREL optional
Records the vertical adjustment of a feature's programmatically-determined
location in terms of staff interline distance; that is, in units of 1/2 the distance
between adjacent staff lines.
when mei:mei_data.URI optional
Indicates the point of occurrence of this feature along a time line. Its
value must be the ID of a when element elsewhere in the document.
wordpos restriction of xs:token optional
Records the position of a syllable within a word.
x xs:decimal optional
Encodes an x coordinate for a feature in an output coordinate system. When
it is necessary to record the placement of a feature in a facsimile image, use the facs
attribute.
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.
xml:lang xs:language optional
Identifies the language of the element's content. The values for this
attribute are language 'tags' as defined in BCP 47. All language tags that make use of
private use sub-tags must be documented in a corresponding language element in the MEI
header whose id attribute is the same as the language tag's value.
y xs:decimal optional
Encodes an y coordinate for a feature in an output coordinate system. When
it is necessary to record the placement of a feature in a facsimile image, use the facs
attribute.

Used By

Elements mei:mei_model.verseLike, mei:note
Element Groups mei:mei_model.rdgPart.critapp, mei:mei_model.syllablePart

Source

<xs:element name="mei_model.sylLike" abstract="true">
  <xs:complexType mixed="true">
    <xs:choice minOccurs="0" maxOccurs="unbounded">
      <xs:group ref="mei:mei_model.textphraseLike.limited"/>
      <xs:element ref="mei:mei_model.editLike"/>
      <xs:element ref="mei:mei_model.transcriptionLike"/>
    </xs:choice>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.lang.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.syl.log.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.syl.vis.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.syl.anl.attributes"/>
  </xs:complexType>
</xs:element>

Sample
