db:entry

Element Information

Model

db:abbrev | db:acronym | db:alt | db:annotation | db:coref | db:date | db:emphasis | db:firstterm | db:footnote | db:footnoteref | db:foreignphrase | db:glossterm | db:inlinemediaobject | db:phrase | db:quote | db:remark | db:subscript | db:superscript | db:trademark | db:wordasword | db:xref | db:link | db:olink | db:anchor | | db:productnumber | db:productname | db:database | db:application | db:hardware | db:citation | db:citerefentry | db:citetitle | db:citebiblioid | db:author | db:person | db:personname | db:org | db:orgname | db:editor | db:jobtitle | db:indexterm | db:replaceable | db:package | db:parameter | db:termdef | db:nonterminal | db:systemitem | db:option | db:optional | db:property | db:inlineequation | db:tag | db:markup | db:token | db:symbol | db:literal | db:code | db:constant | db:email | db:uri | db:guiicon | db:guibutton | db:guimenuitem | db:guimenu | db:guisubmenu | db:guilabel | db:menuchoice | db:mousebutton | db:keycombo | db:keycap | db:keycode | db:keysym | db:shortcut | db:accel | db:prompt | db:envar | db:filename | db:command | db:computeroutput | db:userinput | db:function | db:varname | db:returnvalue | db:type | db:classname | db:exceptionname | db:interfacename | db:methodname | db:modifier | db:initializer | db:ooclass | db:ooexception | db:oointerface | db:errorcode | db:errortext | db:errorname | db:errortype | db:itemizedlist | db:orderedlist | db:simplelist | db:variablelist | db:segmentedlist | db:glosslist | db:bibliolist | db:calloutlist | db:qandaset | db:example | db:figure | db:table | db:equation | db:informalexample | db:informalfigure | db:informaltable | db:informalequation | db:sidebar | db:blockquote | db:address | db:epigraph | db:mediaobject | db:screenshot | db:procedure | db:task | db:productionset | db:constraintdef | db:msgset | db:screen | db:literallayout | db:programlistingco | db:screenco | db:programlisting | db:synopsis | db:bridgehead | db:revhistory | db:funcsynopsis | db:classsynopsis | db:methodsynopsis | db:constructorsynopsis | db:destructorsynopsis | db:fieldsynopsis | db:cmdsynopsis | db:caution | db:important | db:note | db:tip | db:warning | db:para | db:formalpara | db:simpara
Children: db:abbrev, db:accel, db:acronym, db:address, db:alt, db:anchor, db:annotation, db:application, db:author, db:bibliolist, db:blockquote, db:bridgehead, db:calloutlist, db:caution, db:citation, db:citebiblioid, db:citerefentry, db:citetitle, db:classname, db:classsynopsis, db:cmdsynopsis, db:code, db:command, db:computeroutput, db:constant, db:constraintdef, db:constructorsynopsis, db:coref, db:database, db:date, db:destructorsynopsis, db:editor, db:email, db:emphasis, db:envar, db:epigraph, db:equation, db:errorcode, db:errorname, db:errortext, db:errortype, db:example, db:exceptionname, db:fieldsynopsis, db:figure, db:filename, db:firstterm, db:footnote, db:footnoteref, db:foreignphrase, db:formalpara, db:funcsynopsis, db:function, db:glosslist, db:glossterm, db:guibutton, db:guiicon, db:guilabel, db:guimenu, db:guimenuitem, db:guisubmenu, db:hardware, db:important, db:indexterm, db:informalequation, db:informalexample, db:informalfigure, db:informaltable, db:initializer, db:inlineequation, db:inlinemediaobject, db:interfacename, db:itemizedlist, db:jobtitle, db:keycap, db:keycode, db:keycombo, db:keysym, db:link, db:literal, db:literallayout, db:markup, db:mediaobject, db:menuchoice, db:methodname, db:methodsynopsis, db:modifier, db:mousebutton, db:msgset, db:nonterminal, db:note, db:olink, db:ooclass, db:ooexception, db:oointerface, db:option, db:optional, db:orderedlist, db:org, db:orgname, db:package, db:para, db:parameter, db:person, db:personname, db:phrase, db:procedure, db:productionset, db:productname, db:productnumber, db:programlisting, db:programlistingco, db:prompt, db:property, db:qandaset, db:quote, db:remark, db:replaceable, db:returnvalue, db:revhistory, db:screen, db:screenco, db:screenshot, db:segmentedlist, db:shortcut, db:sidebar, db:simpara, db:simplelist, db:subscript, db:superscript, db:symbol, db:synopsis, db:systemitem, db:table, db:tag, db:task, db:termdef, db:tip, db:token, db:trademark, db:type, db:uri, db:userinput, db:variablelist, db:varname, db:warning, db:wordasword, db:xref

Attributes

QName Type Fixed Default Use Inheritable Annotation
align restriction of xs:token optional
annotations optional
arch optional
audience optional
char optional
charoff restriction of xs:nonNegativeInteger optional
colname optional
colsep db:zeroorone.type optional
condition optional
conformance optional
dir restriction of xs:token optional
headers xs:IDREFS optional
linkend xs:IDREF optional
morerows xs:nonNegativeInteger optional
nameend optional
namest optional
os optional
outputformat optional
prefix optional
property optional
remap optional
resource optional
revision optional
revisionflag restriction of xs:token optional
role optional
rotate db:zeroorone.type optional
rowsep db:zeroorone.type optional
scope restriction of xs:token optional
security optional
spanname optional
typeof optional
userlevel optional
valign restriction of xs:token optional
vendor optional
version optional
vocab xs:anyURI optional
wordsize optional
xlink:actuate xlink:actuateType optional
xlink:arcrole xlink:arcroleType optional
xlink:href xlink:hrefType optional
xlink:role xlink:roleType optional
xlink:show xlink:showType optional
xlink:title xlink:titleAttrType optional
xlink:type xlink:typeType optional
xml:base optional
xml:id xs:ID optional
xml:lang optional
xreflabel optional

Used By

Element db:row

Source

<xs:element name="entry">
  <xs:complexType mixed="true">
    <xs:choice>
      <xs:group ref="db:all.inlines" minOccurs="0" maxOccurs="unbounded"/>
      <xs:group ref="db:all-i.blocks" minOccurs="0" maxOccurs="unbounded"/>
    </xs:choice>
    <xs:attribute name="role"/>
    <xs:attribute name="morerows" type="xs:nonNegativeInteger"/>
    <xs:attribute name="rotate" type="db:zeroorone.type"/>
    <xs:attribute name="scope">
      <xs:simpleType>
        <xs:restriction base="xs:token">
          <xs:enumeration value="row"/>
          <xs:enumeration value="col"/>
          <xs:enumeration value="rowgroup"/>
          <xs:enumeration value="colgroup"/>
        </xs:restriction>
      </xs:simpleType>
    </xs:attribute>
    <xs:attributeGroup ref="db:common.attributes"/>
    <xs:attributeGroup ref="db:common.linking.attributes"/>
    <xs:attributeGroup ref="db:valign.attribute"/>
    <xs:attributeGroup ref="db:char.attribute"/>
    <xs:attributeGroup ref="db:charoff.attribute"/>
    <xs:attributeGroup ref="db:colsep.attribute"/>
    <xs:attributeGroup ref="db:rowsep.attribute"/>
    <xs:attributeGroup ref="db:column-spec.attributes"/>
    <xs:attributeGroup ref="db:align.attribute"/>
    <xs:attribute name="headers" type="xs:IDREFS"/>
  </xs:complexType>
</xs:element>

Sample
