db:alt

Element Information

Model

db:inlinemediaobject
Children: db:inlinemediaobject

Attributes

QName Type Fixed Default Use Inheritable Annotation
annotations optional
arch optional
audience optional
condition optional
conformance optional
dir restriction of xs:token optional
os optional
outputformat optional
prefix optional
property optional
remap optional
resource optional
revision optional
revisionflag restriction of xs:token optional
role optional
security optional
typeof optional
userlevel optional
vendor optional
version optional
vocab xs:anyURI optional
wordsize optional
xml:base optional
xml:id xs:ID optional
xml:lang optional
xreflabel optional

Used By

Elements db:area, db:areaset/db:area, db:equation, db:informalequation, db:informaltable, db:inlineequation, db:inlinemediaobject, db:mediaobject, db:table
Element Group db:ubiq.inlines

Source

<xs:element name="alt">
  <xs:complexType mixed="true">
    <xs:sequence minOccurs="0" maxOccurs="unbounded">
      <xs:element ref="db:inlinemediaobject"/>
    </xs:sequence>
    <xs:attribute name="role"/>
    <xs:attributeGroup ref="db:common.attributes"/>
  </xs:complexType>
</xs:element>

Sample
