db:equation

Element Information

Model

(db:title | db:titleabbrev) , db:info{0,1} , db:alt{0,1} , (db:mediaobject+ | db:mathphrase+ | ANY element from namespace(s) 'http://www.w3.org/1998/Math/MathML') , db:caption{0,1}
Children: db:alt, db:caption, db:info, db:mathphrase, db:mediaobject, db:title, db:titleabbrev

Attributes

QName Type Fixed Default Use Inheritable Annotation
annotations optional
arch optional
audience optional
condition optional
conformance optional
dir restriction of xs:token optional
floatstyle optional
label optional
linkend xs:IDREF optional
os optional
outputformat optional
pgwide db:zeroorone.type optional
prefix optional
property optional
remap optional
resource optional
revision optional
revisionflag restriction of xs:token optional
role optional
security optional
typeof optional
userlevel optional
vendor optional
version optional
vocab xs:anyURI optional
wordsize optional
xlink:actuate xlink:actuateType optional
xlink:arcrole xlink:arcroleType optional
xlink:href xlink:hrefType optional
xlink:role xlink:roleType optional
xlink:show xlink:showType optional
xlink:title xlink:titleAttrType optional
xlink:type xlink:typeType optional
xml:base optional
xml:id xs:ID optional
xml:lang optional
xreflabel optional

Used By

Element Group db:formal.blocks

Source

<xs:element name="equation">
  <xs:complexType>
    <xs:sequence>
      <xs:group ref="db:_info.title.only" minOccurs="0"/>
      <xs:element ref="db:alt" minOccurs="0"/>
      <xs:group ref="db:equation.content"/>
      <xs:element ref="db:caption" minOccurs="0"/>
    </xs:sequence>
    <xs:attribute name="role"/>
    <xs:attributeGroup ref="db:common.attributes"/>
    <xs:attributeGroup ref="db:common.linking.attributes"/>
    <xs:attributeGroup ref="db:label.attribute"/>
    <xs:attributeGroup ref="db:pgwide.attribute"/>
    <xs:attributeGroup ref="db:floatstyle.attribute"/>
  </xs:complexType>
</xs:element>

Sample
