db:informaltable

Element Information

Model

db:info{0,1} , (((db:alt | db:indexterm | db:textobject) , (db:mediaobject+ | db:tgroup+) , db:caption{0,1}) | ((db:col* | db:colgroup*) , db:thead{0,1} , db:tfoot{0,1} , (db:tbody+ | db:tr+)))
Children: db:alt, db:caption, db:col, db:colgroup, db:indexterm, db:info, db:mediaobject, db:tbody, db:textobject, db:tfoot, db:tgroup, db:thead, db:tr

Attributes

QName Type Fixed Default Use Inheritable Annotation
annotations optional
arch optional
audience optional
border xs:nonNegativeInteger optional
cellpadding optional
cellspacing optional
class optional
colsep db:zeroorone.type optional
condition optional
conformance optional
dir restriction of xs:token optional
floatstyle optional
frame restriction of xs:token optional
label optional
lang optional
linkend xs:IDREF optional
onclick optional
ondblclick optional
onkeydown optional
onkeypress optional
onkeyup optional
onmousedown optional
onmousemove optional
onmouseout optional
onmouseover optional
onmouseup optional
orient restriction of xs:token optional
os optional
outputformat optional
pgwide db:zeroorone.type optional
prefix optional
property optional
remap optional
resource optional
revision optional
revisionflag restriction of xs:token optional
role optional
rowheader restriction of xs:token optional
rowsep db:zeroorone.type optional
rules restriction of xs:token optional
security optional
shortentry db:zeroorone.type optional
style optional
summary optional
tabstyle optional
title optional
tocentry db:zeroorone.type optional
typeof optional
userlevel optional
vendor optional
version optional
vocab xs:anyURI optional
width optional
wordsize optional
xlink:actuate xlink:actuateType optional
xlink:arcrole xlink:arcroleType optional
xlink:href xlink:hrefType optional
xlink:role xlink:roleType optional
xlink:show xlink:showType optional
xlink:title xlink:titleAttrType optional
xlink:type xlink:typeType optional
xml:base optional
xml:id xs:ID optional
xml:lang optional
xreflabel optional

Used By

Element Group db:informal.blocks

Source

<xs:element name="informaltable">
  <xs:complexType>
    <xs:sequence>
      <xs:group ref="db:_info.title.forbidden" minOccurs="0" maxOccurs="1"/>
      <xs:choice>
        <xs:sequence>
          <!-- CALS -->
          <xs:choice minOccurs="0" maxOccurs="unbounded">
            <xs:element ref="db:alt"/>
            <xs:group ref="db:indexing.inlines"/>
            <xs:element ref="db:textobject"/>
          </xs:choice>
          <xs:choice>
            <xs:element ref="db:mediaobject" minOccurs="1" maxOccurs="unbounded"/>
            <xs:element ref="db:tgroup" minOccurs="1" maxOccurs="unbounded"/>
          </xs:choice>
          <xs:element ref="db:caption" minOccurs="0" maxOccurs="1"/>
        </xs:sequence>
        <xs:sequence>
          <!-- HTML -->
          <xs:choice>
            <xs:element ref="db:col" minOccurs="0" maxOccurs="unbounded"/>
            <xs:element ref="db:colgroup" minOccurs="0" maxOccurs="unbounded"/>
          </xs:choice>
          <xs:element ref="db:thead" minOccurs="0" maxOccurs="1"/>
          <xs:element ref="db:tfoot" minOccurs="0" maxOccurs="1"/>
          <xs:choice>
            <xs:element ref="db:tbody" minOccurs="1" maxOccurs="unbounded"/>
            <xs:element ref="db:tr" minOccurs="1" maxOccurs="unbounded"/>
          </xs:choice>
        </xs:sequence>
      </xs:choice>
    </xs:sequence>
    <!-- Common and CALS -->
    <xs:attribute name="role"/>
    <xs:attributeGroup ref="db:label.attribute"/>
    <xs:attributeGroup ref="db:common.attributes"/>
    <xs:attributeGroup ref="db:common.linking.attributes"/>
    <xs:attributeGroup ref="db:tabstyle.attribute"/>
    <xs:attributeGroup ref="db:floatstyle.attribute"/>
    <xs:attributeGroup ref="db:orient.attribute"/>
    <xs:attributeGroup ref="db:colsep.attribute"/>
    <xs:attributeGroup ref="db:rowsep.attribute"/>
    <xs:attributeGroup ref="db:pgwide.attribute"/>
    <xs:attribute name="shortentry" type="db:zeroorone.type"/>
    <xs:attribute name="tocentry" type="db:zeroorone.type"/>
    <xs:attributeGroup ref="db:rowheader.attribute"/>
    <!-- HTML -->
    <xs:attributeGroup ref="db:html.coreattrs"/>
    <xs:attributeGroup ref="db:html.i18n"/>
    <xs:attributeGroup ref="db:html.events"/>
    <xs:attributeGroup ref="db:html.table.attributes"/>
    <!-- Merged -->
    <xs:attributeGroup ref="db:merged-html-cals-frame.attribute"/>
  </xs:complexType>
</xs:element>

Sample
