db:tfoot

Element Information

Model

(db:colspec* , db:row+) | (db:tr+)
Children: db:colspec, db:row, db:tr

Attributes

QName Type Fixed Default Use Inheritable Annotation
align restriction of xs:token optional
annotations optional
arch optional
audience optional
charoff optional
class optional
condition optional
conformance optional
dir restriction of xs:token optional
lang optional
linkend xs:IDREF optional
onclick optional
ondblclick optional
onkeydown optional
onkeypress optional
onkeyup optional
onmousedown optional
onmousemove optional
onmouseout optional
onmouseover optional
onmouseup optional
os optional
outputformat optional
prefix optional
property optional
remap optional
resource optional
revision optional
revisionflag restriction of xs:token optional
role optional
security optional
style optional
title optional
typeof optional
userlevel optional
valign restriction of xs:token optional
vendor optional
version optional
vocab xs:anyURI optional
wordsize optional
xlink:actuate xlink:actuateType optional
xlink:arcrole xlink:arcroleType optional
xlink:href xlink:hrefType optional
xlink:role xlink:roleType optional
xlink:show xlink:showType optional
xlink:title xlink:titleAttrType optional
xlink:type xlink:typeType optional
xml:base optional
xml:id xs:ID optional
xml:lang optional
xreflabel optional

Used By

Elements db:informaltable, db:table, db:tgroup

Source

<xs:element name="tfoot">
  <xs:complexType>
    <xs:choice>
      <xs:sequence>
        <!-- CALS -->
        <xs:element ref="db:colspec" minOccurs="0" maxOccurs="unbounded"/>
        <xs:element ref="db:row" minOccurs="1" maxOccurs="unbounded"/>
      </xs:sequence>
      <xs:sequence>
        <!-- HTML -->
        <xs:element ref="db:tr" minOccurs="1" maxOccurs="unbounded"/>
      </xs:sequence>
    </xs:choice>
    <!-- Common and CALS -->
    <xs:attribute name="role"/>
    <xs:attributeGroup ref="db:common.attributes"/>
    <xs:attributeGroup ref="db:common.linking.attributes"/>
    <xs:attributeGroup ref="db:valign.attribute"/>
    <!-- HTML -->
    <xs:attributeGroup ref="db:html.coreattrs"/>
    <xs:attributeGroup ref="db:html.i18n"/>
    <xs:attributeGroup ref="db:html.events"/>
    <xs:attributeGroup ref="db:html.cellhalign"/>
  </xs:complexType>
</xs:element>

Sample
