db:colspec

Element Information

Model

Attributes

QName Type Fixed Default Use Inheritable Annotation
align restriction of xs:token optional
annotations optional
arch optional
audience optional
char optional
charoff restriction of xs:nonNegativeInteger optional
colname optional
colnum xs:positiveInteger optional
colsep db:zeroorone.type optional
colwidth optional
condition optional
conformance optional
dir restriction of xs:token optional
linkend xs:IDREF optional
os optional
outputformat optional
prefix optional
property optional
remap optional
resource optional
revision optional
revisionflag restriction of xs:token optional
role optional
rowheader restriction of xs:token optional
rowsep db:zeroorone.type optional
security optional
typeof optional
userlevel optional
vendor optional
version optional
vocab xs:anyURI optional
wordsize optional
xlink:actuate xlink:actuateType optional
xlink:arcrole xlink:arcroleType optional
xlink:href xlink:hrefType optional
xlink:role xlink:roleType optional
xlink:show xlink:showType optional
xlink:title xlink:titleAttrType optional
xlink:type xlink:typeType optional
xml:base optional
xml:id xs:ID optional
xml:lang optional
xreflabel optional

Used By

Elements db:entrytbl, db:tfoot, db:tgroup, db:thead

Source

<xs:element name="colspec">
  <xs:complexType>
    <xs:complexContent>
      <xs:restriction base="xs:anyType">
        <xs:attribute name="role"/>
        <xs:attribute name="colnum" type="xs:positiveInteger"/>
        <xs:attribute name="colwidth"/>
        <xs:attributeGroup ref="db:common.attributes"/>
        <xs:attributeGroup ref="db:common.linking.attributes"/>
        <xs:attributeGroup ref="db:char.attribute"/>
        <xs:attributeGroup ref="db:charoff.attribute"/>
        <xs:attributeGroup ref="db:colsep.attribute"/>
        <xs:attributeGroup ref="db:rowsep.attribute"/>
        <xs:attributeGroup ref="db:align.attribute"/>
        <xs:attributeGroup ref="db:rowheader.attribute"/>
        <xs:attribute name="colname"/>
      </xs:restriction>
    </xs:complexContent>
  </xs:complexType>
</xs:element>

Sample
