db:article

Element Information

Model

(db:title | db:titleabbrev | db:subtitle) , db:info{0,1} , (db:glossary | db:bibliography | db:index | db:toc | db:acknowledgements | db:dedication | db:appendix | db:colophon) , (((db:itemizedlist | db:orderedlist | db:simplelist | db:variablelist | db:segmentedlist | db:glosslist | db:bibliolist | db:calloutlist | db:qandaset | db:example | db:figure | db:table | db:equation | db:informalexample | db:informalfigure | db:informaltable | db:informalequation | db:sidebar | db:blockquote | db:address | db:epigraph | db:mediaobject | db:screenshot | db:procedure | db:task | db:productionset | db:constraintdef | db:msgset | db:screen | db:literallayout | db:programlistingco | db:screenco | db:programlisting | db:synopsis | db:bridgehead | db:revhistory | db:funcsynopsis | db:classsynopsis | db:methodsynopsis | db:constructorsynopsis | db:destructorsynopsis | db:fieldsynopsis | db:cmdsynopsis | db:caution | db:important | db:note | db:tip | db:warning | db:remark | db:para | db:formalpara | db:simpara | db:annotation | db:indexterm) , ((db:section* , db:simplesect*) | (db:sect1+ , db:simplesect*) | db:refentry+)) | (db:section* , db:simplesect*) | (db:sect1+ , db:simplesect*) | db:refentry+)
Children: db:acknowledgements, db:address, db:annotation, db:appendix, db:bibliography, db:bibliolist, db:blockquote, db:bridgehead, db:calloutlist, db:caution, db:classsynopsis, db:cmdsynopsis, db:colophon, db:constraintdef, db:constructorsynopsis, db:dedication, db:destructorsynopsis, db:epigraph, db:equation, db:example, db:fieldsynopsis, db:figure, db:formalpara, db:funcsynopsis, db:glossary, db:glosslist, db:important, db:index, db:indexterm, db:info, db:informalequation, db:informalexample, db:informalfigure, db:informaltable, db:itemizedlist, db:literallayout, db:mediaobject, db:methodsynopsis, db:msgset, db:note, db:orderedlist, db:para, db:procedure, db:productionset, db:programlisting, db:programlistingco, db:qandaset, db:refentry, db:remark, db:revhistory, db:screen, db:screenco, db:screenshot, db:sect1, db:section, db:segmentedlist, db:sidebar, db:simpara, db:simplelist, db:simplesect, db:subtitle, db:synopsis, db:table, db:task, db:tip, db:title, db:titleabbrev, db:toc, db:variablelist, db:warning

Attributes

QName Type Fixed Default Use Inheritable Annotation
annotations optional
arch optional
audience optional
class restriction of xs:token optional
condition optional
conformance optional
dir restriction of xs:token optional
label optional
linkend xs:IDREF optional
os optional
outputformat optional
prefix optional
property optional
remap optional
resource optional
revision optional
revisionflag restriction of xs:token optional
role optional
security optional
status optional
typeof optional
userlevel optional
vendor optional
version optional
vocab xs:anyURI optional
wordsize optional
xlink:actuate xlink:actuateType optional
xlink:arcrole xlink:arcroleType optional
xlink:href xlink:hrefType optional
xlink:role xlink:roleType optional
xlink:show xlink:showType optional
xlink:title xlink:titleAttrType optional
xlink:type xlink:typeType optional
xml:base optional
xml:id xs:ID optional
xml:lang optional
xreflabel optional

Used By

Element Groups db:components, db:set.components

Source

<xs:element name="article">
  <xs:complexType>
    <xs:sequence>
      <xs:group ref="db:_info.title.req" minOccurs="0"/>
      <xs:group ref="db:article.navigation.components" minOccurs="0" maxOccurs="unbounded"/>
      <xs:choice>
        <xs:sequence>
          <xs:group ref="db:all.blocks" minOccurs="1" maxOccurs="unbounded"/>
          <xs:group ref="db:article.components" minOccurs="0"/>
        </xs:sequence>
        <xs:group ref="db:article.components"/>
      </xs:choice>
    </xs:sequence>
    <xs:attribute name="role"/>
    <xs:attributeGroup ref="db:common.attributes"/>
    <xs:attributeGroup ref="db:common.linking.attributes"/>
    <xs:attribute name="label"/>
    <xs:attributeGroup ref="db:status.attribute"/>
    <xs:attribute name="class">
      <xs:simpleType>
        <xs:restriction base="xs:token">
          <xs:enumeration value="faq"/>
          <xs:enumeration value="journalarticle"/>
          <xs:enumeration value="productsheet"/>
          <xs:enumeration value="specification"/>
          <xs:enumeration value="techreport"/>
          <xs:enumeration value="whitepaper"/>
        </xs:restriction>
      </xs:simpleType>
    </xs:attribute>
  </xs:complexType>
</xs:element>

Sample
