mei:extent

Used to express size in terms other than physical dimensions, such as number
of pages, number of records in file, number of bytes, performance duration for music, audio
recordings and visual projections, etc.

Element Information

Model

Attributes

QName Type Fixed Default Use Inheritable Annotation
analog xs:string optional
Contains a reference to a field or element in another descriptive encoding
system to which this MEI element is comparable.
facs restriction of list of mei:mei_data.URI optional
Permits the current element to reference a facsimile surface or image zone
which corresponds to it.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
n optional
Provides a number-like designation for an element.
translit xs:NMTOKEN optional
Specifies the transliteration technique used.
unit union of(xs:NMTOKEN, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token, restriction of xs:token) optional
Indicates the unit of measurement. Suggested values include: 1] byte; 2]
char; 3] cm; 4] in; 5] issue; 6] mm; 7] page; 8] pc; 9] pt; 10] px; 11] record; 12] vol;
13] vu
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.
xml:lang xs:language optional
Identifies the language of the element's content. The values for this
attribute are language 'tags' as defined in BCP 47. All language tags that make use of
private use sub-tags must be documented in a corresponding language element in the MEI
header whose id attribute is the same as the language tag's value.

Used By

Source

<xs:element name="extent" substitutionGroup="mei:mei_model.physDescPart">
  <xs:annotation>
    <xs:documentation>Used to express size in terms other than physical dimensions, such as number of pages, number of records in file, number of bytes, performance duration for music, audio recordings and visual projections, etc.</xs:documentation>
  </xs:annotation>
  <xs:complexType mixed="true">
    <xs:group minOccurs="0" maxOccurs="unbounded" ref="mei:mei_model.textphraseLike.limited"/>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.bibl.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.lang.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.measurement.attributes"/>
  </xs:complexType>
</xs:element>

Sample
