fig-model

Element Group Information

Model

(object-id) , label{0,1} , (caption) , (contrib-group) , (abstract) , (kwd-group) , (alt-text | long-desc | email | ext-link | uri) , (disp-formula | disp-formula-group | chem-struct-wrap | disp-quote | speech | statement | verse-group | table-wrap | p | def-list | list | alternatives | array | code | graphic | media | preformat) , (attrib | permissions)

Children: abstract, alt-text, alternatives, array, attrib, caption, chem-struct-wrap, code, contrib-group, def-list, disp-formula, disp-formula-group, disp-quote, email, ext-link, graphic, kwd-group, label, list, long-desc, media, object-id, p, permissions, preformat, speech, statement, table-wrap, uri, verse-group

Used By

Element	fig
Element Group	supplementary-material-model

Source

<xsd:group name="fig-model">
  <xsd:sequence>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="id.class"/>
    </xsd:choice>
    <xsd:element ref="label" minOccurs="0"/>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="caption.class"/>
    </xsd:choice>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="contrib-group.class"/>
    </xsd:choice>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="abstract.class"/>
    </xsd:choice>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="kwd-group.class"/>
    </xsd:choice>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="access.class"/>
      <xsd:group ref="address-link.class"/>
    </xsd:choice>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="block-math.class"/>
      <xsd:group ref="chem-struct-wrap.class"/>
      <xsd:group ref="intable-para.class"/>
      <xsd:group ref="just-table.class"/>
      <xsd:group ref="just-para.class"/>
      <xsd:group ref="list.class"/>
      <xsd:group ref="simple-display.class"/>
    </xsd:choice>
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
      <xsd:group ref="display-back-matter.class"/>
    </xsd:choice>
  </xsd:sequence>
</xsd:group>
