mei:relatedItem

(related item) – Contains or references another bibliographic item which is
related to the present one.

Element Information

Model

mei:bibl
Children: mei:bibl

Attributes

QName Type Fixed Default Use Inheritable Annotation
analog xs:string optional
Contains a reference to a field or element in another descriptive encoding
system to which this MEI element is comparable.
data restriction of list of mei:mei_data.URI optional
Used to link metadata elements to one or more data-containing
elements.
evaluate restriction of xs:token optional
Specifies the intended meaning when a participant in a relationship is
itself a pointer.
facs restriction of list of mei:mei_data.URI optional
Permits the current element to reference a facsimile surface or image zone
which corresponds to it.
label xs:string optional
Provides a name or label for an element. The value may be any
string.
n optional
Provides a number-like designation for an element.
rel restriction of xs:token required
Describes the relationship between the <relatedItem> and the
resource described in the parent element, i.e., <bibl>, <source> or
<relatedItem>. The values are based on MODS version 3.4. The subject of these
relations is always the <relatedItem>, and the object is always the parent of the
<relatedItem>. "preceding" and "succeeding" indicate temporal
order.
subtype xs:NMTOKEN optional
Provide any sub-classification for the element, additional to that given
by its type attribute.
target restriction of list of mei:mei_data.URI optional
Allows the use of one or more previously-undeclared URIs to identify
passive participants in a relationship; that is, the entities pointed
"to".
targettype xs:NMTOKEN optional
Characterization of target resource(s) using any convenient classification
scheme or typology.
type xs:NMTOKEN optional
Characterizes the element in some sense, using any convenient
classification scheme or typology.
xlink:actuate restriction of xs:token optional
Defines whether a link occurs automatically or must be requested by the
user.
xlink:role mei:mei_data.URI optional
Characterization of the relationship between resources. The value of the
role attribute must be a URI.
xlink:show restriction of xs:token optional
Defines how a remote resource is rendered.
xml:base mei:mei_data.URI optional
Provides a base URI reference with which applications can resolve relative
URI references into absolute URI references.
xml:id xs:ID optional
Regularizes the naming of an element and thus facilitates building links
between it and other resources. Each id attribute within a document must have a unique
value.

Used By

Element Group mei:mei_model.biblPart

Source

<xs:element name="relatedItem">
  <xs:annotation>
    <xs:documentation>(related item) – Contains or references another bibliographic item which is related to the present one.</xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:group minOccurs="0" maxOccurs="unbounded" ref="mei:mei_model.biblLike"/>
    <xs:attributeGroup ref="mei:mei_att.datapointing.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.common.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.bibl.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.facsimile.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.pointing.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.targeteval.attributes"/>
    <xs:attributeGroup ref="mei:mei_att.typed.attributes"/>
    <xs:attribute name="rel" use="required">
      <xs:annotation>
        <xs:documentation>Describes the relationship between the <relatedItem> and the resource described in the parent element, i.e., <bibl>, <source> or <relatedItem>. The values are based on MODS version 3.4. The subject of these relations is always the <relatedItem>, and the object is always the parent of the <relatedItem>. "preceding" and "succeeding" indicate temporal order.</xs:documentation>
      </xs:annotation>
      <xs:simpleType>
        <xs:restriction base="xs:token">
          <xs:enumeration value="preceding">
            <xs:annotation>
              <xs:documentation>Predecessor of the resource.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="succeeding">
            <xs:annotation>
              <xs:documentation>Successor to the resource.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="original">
            <xs:annotation>
              <xs:documentation>Original form of the resource.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="host">
            <xs:annotation>
              <xs:documentation>Parent containing the resource.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="constituent">
            <xs:annotation>
              <xs:documentation>Intellectual or physical component of the resource.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="otherVersion">
            <xs:annotation>
              <xs:documentation>Version of the resource's intellectual content not changed enough to be a different work.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="otherFormat">
            <xs:annotation>
              <xs:documentation>Version of the resource in a different physical format.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="isReferencedBy">
            <xs:annotation>
              <xs:documentation>Published bibliographic description, review, abstract, or index of the resource's content.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
          <xs:enumeration value="references">
            <xs:annotation>
              <xs:documentation>Cited or referred to in the resource.</xs:documentation>
            </xs:annotation>
          </xs:enumeration>
        </xs:restriction>
      </xs:simpleType>
    </xs:attribute>
  </xs:complexType>
</xs:element>

Sample
