td

Element Information

Model

email | ext-link | uri | inline-supplementary-material | related-article | related-object | hr | bold | fixed-case | italic | monospace | overline | overline-start | overline-end | roman | sans-serif | sc | serif | strike | underline | underline-start | underline-end | ruby | alternatives | inline-graphic | private-char | chem-struct | inline-formula | tex-math | m:math | abbrev | index-term | index-term-range-end | milestone-end | milestone-start | named-content | styled-content | fn | target | xref | sub | sup | x | disp-formula | disp-formula-group | break | chem-struct-wrap | citation-alternatives | element-citation | mixed-citation | def-list | list | p | answer | answer-set | explanation | question | question-wrap | question-wrap-group | array | code | graphic | media | preformat
Children: abbrev, alternatives, answer, answer-set, array, bold, break, chem-struct, chem-struct-wrap, citation-alternatives, code, def-list, disp-formula, disp-formula-group, element-citation, email, explanation, ext-link, fixed-case, fn, graphic, hr, index-term, index-term-range-end, inline-formula, inline-graphic, inline-supplementary-material, italic, list, m:math, media, milestone-end, milestone-start, mixed-citation, monospace, named-content, overline, overline-end, overline-start, p, preformat, private-char, question, question-wrap, question-wrap-group, related-article, related-object, roman, ruby, sans-serif, sc, serif, strike, styled-content, sub, sup, target, tex-math, underline, underline-end, underline-start, uri, x, xref

Attributes

QName Type Fixed Default Use Inheritable Annotation
abbr xsd:string optional
align restriction of xsd:NMTOKEN optional
axis xsd:string optional
char xsd:string optional
charoff xsd:string optional
colspan xsd:string 1 optional
content-type xsd:string optional
headers xsd:IDREFS optional
id xsd:ID optional
rowspan xsd:string 1 optional
scope restriction of xsd:NMTOKEN optional
style xsd:string optional
valign restriction of xsd:NMTOKEN optional
xml:base xs:anyURI optional
<div>
  <h3>base (as an attribute name)</h3>
  <p>denotes an attribute whose value provides a URI to be used as the base for interpreting any relative URIs in the scope of the element on which it appears; its value is inherited. This name is reserved by virtue of its definition in the XML Base specification.</p>
  <p>See
    <a href="http://www.w3.org/TR/xmlbase/">http://www.w3.org/TR/xmlbase/</a>for information about this attribute.</p>
</div>

Used By

Element Group tr.content

Source

<xsd:element name="td">
  <xsd:annotation>
    <xsd:documentation/>
  </xsd:annotation>
  <xsd:complexType mixed="true">
    <xsd:group ref="td.content" minOccurs="0" maxOccurs="unbounded"/>
    <xsd:attribute name="abbr" use="optional" type="xsd:string"/>
    <xsd:attribute name="align" use="optional">
      <xsd:simpleType>
        <xsd:annotation>
          <xsd:documentation/>
        </xsd:annotation>
        <xsd:restriction base="xsd:NMTOKEN">
          <xsd:enumeration value="center"/>
          <xsd:enumeration value="char"/>
          <xsd:enumeration value="justify"/>
          <xsd:enumeration value="left"/>
          <xsd:enumeration value="right"/>
        </xsd:restriction>
      </xsd:simpleType>
    </xsd:attribute>
    <xsd:attribute name="axis" use="optional" type="xsd:string"/>
    <xsd:attribute name="char" use="optional" type="xsd:string"/>
    <xsd:attribute name="charoff" use="optional" type="xsd:string"/>
    <xsd:attribute name="colspan" use="optional" default="1" type="xsd:string"/>
    <xsd:attribute name="content-type" use="optional" type="xsd:string"/>
    <xsd:attribute name="headers" use="optional" type="xsd:IDREFS"/>
    <xsd:attribute name="id" use="optional" type="xsd:ID"/>
    <xsd:attribute name="rowspan" use="optional" default="1" type="xsd:string"/>
    <xsd:attribute name="scope" use="optional">
      <xsd:simpleType>
        <xsd:annotation>
          <xsd:documentation/>
        </xsd:annotation>
        <xsd:restriction base="xsd:NMTOKEN">
          <xsd:enumeration value="col"/>
          <xsd:enumeration value="colgroup"/>
          <xsd:enumeration value="row"/>
          <xsd:enumeration value="rowgroup"/>
        </xsd:restriction>
      </xsd:simpleType>
    </xsd:attribute>
    <xsd:attribute name="style" use="optional" type="xsd:string"/>
    <xsd:attribute name="valign" use="optional">
      <xsd:simpleType>
        <xsd:annotation>
          <xsd:documentation/>
        </xsd:annotation>
        <xsd:restriction base="xsd:NMTOKEN">
          <xsd:enumeration value="baseline"/>
          <xsd:enumeration value="bottom"/>
          <xsd:enumeration value="middle"/>
          <xsd:enumeration value="top"/>
        </xsd:restriction>
      </xsd:simpleType>
    </xsd:attribute>
    <xsd:attribute ref="xml:base" use="optional"/>
  </xsd:complexType>
</xsd:element>

Sample
